55W 0-10V Deep Dimming T5 Ballast Driver Flicker-Free

Features:

a. EMC: EN55015, J55015 (H20), FCC 47CFR Part 15 Class A

b. Comply with PSE, CE & CCC. RoHs compliant;

c. T5 Ballast style metal Shell, Silicone Potting;

b. Water Resistant and Dust Proof Design: IP20, NEMA1,

for Dusty, Damp, Wet Locations;

d. Standard electrical box for installation;

e. Active Power Factor Correction technology to reduce

power consumption;

f. Safety Isolation between Primary and Secondary.

g. Surge Immunity (Lightning Protection): Comply with

EN61000-4-5, 2KV/4KV, 8/20usec, transient protection.



Product parameters：

T5 Ballast, Programmable, 0-10V Dimming, Step Dimming	Input Voltage Vac	Power Factor		Output Voltage Vdc	Programmable Current mA	Voltage Accuracy %	Typical Efficiency %	Location
LX55W Series		@120V	@230V
LX55W-55-PC1500-SRD	108~305	0.97	0.95	12-55	300-1500	±5	88	Indoor



Product type:T5 Ballast, 0-10V Deep Dimming, Programmable, NTC Control, Flicker-Free, Step Dimming

Application:LED Panel Light, LED Downlight, LED Grille light

Size:360mm(L)×30mm(W)×26mm(H)

Weight:350g

Warranty:Five years



1. Operating Temperature: −20 to +60°C, Tc 90°C Maximum;

2. Storage Temperature: −40 to +85°C;

3. Humidity (non-condensing): 5% to 95%RH;

4. Cooling: Convection;

5. Vibration Frequency: 5 ~ 55HZ/2g, 30 minutes;

6. Impact Resistance: 1g/S;

7. MTBF@Tc 70°C: 352,000 hours @ Full Load per MIL-217 Notice 2.;

8. LIFE@Tc 70°C: 50,000 hours @ Full Load per MIL-217 Notice 2.;

9. Maximum Input Current: 0.56A (@ 120V, full load);

a. Input Surge Current: <30A (25°C, 230V, cold start);

b. Constant Voltage Regulation: ±4%, Over Input Line Variation;

c. Load Regulation Accuracy: ±3%;

d. Output Voltage Ripple: <4%*Io

e. 0-10V Dimming Input: 0-10V/2mA;

f. Dimming Output Current Range: 0-100%;

g. Resistance Programmable Output Current: 100-1500mA;

h. Module Temperature Protection using External NTC Control;

i. Standby Power: <0.4W@120V, <0.8W@230V, <1.0W@277V;

j. Protection: Output over-voltage protection;

Output over-current protection;

Output short circuit, auto-recovery;

k. Lightning & transient protection built in.
