25W Triac Dimming Driver LT25W Indoor No Flicker No Shimmer No Buzzing

Features:

1. Drive Mode: TRIAC Dimming, Constant Current

2. Technology: Single-stage PFC technology

3. Input Voltage: 108 to 132VAC, 180 to 305VAC, 47-63HZ

4. Output Power: 25 watts max.

5. Output Dimmable Current Range: 10-100%

6. Surge Immunity ( Lightning Protection ):

Comply with EN61000-4-5, AC line to line 2KV

7. Safety: EN61347, J61347 ( H20 ), UL8750, CSA C22.2

8. EMC: EN55015, J55015 ( H20 ), FCC 47CFR Part 15 Class B

9. Comply with UL, PSE, CE & CCC, RoHs compliant;

a. Plastic Shell, Silicone Potting, Up to 120°C;

b. Water Resistant and Dust Proof Design: IP65, NEMA4,

for Dry, Damp, Wet Locations;

c. Safety Isolation between Primary and Secondary.



Product parameters：



TRIAC, ELV Dimming	Input Voltage Vac	Power Factor		Output Voltage Vdc	Dimming Current mA	Current Accuracy %	Typical Efficiency %	Location
LT25W Series		@120V	@230V
LT25W-72-C0350	108-305	0.99	0.95	47-72	35-350	±10	87	Indoor
LT25W-48-C0520	108-305	0.99	0.95	32-48	52-520	±10	87	Indoor
LT25W-36-C0700	108-305	0.99	0.95	24-36	70-700	±10	86	Indoor
LT25W-28-C0850	108-305	0.99	0.95	18-28	85-850	±10	86	Indoor
LT25W-24-C1040	108-305	0.99	0.95	16-24	104-1040	±10	85	Indoor



Product type:TE & LE Dimming Driver, The patent technology of YG

Application:LED Lamps, LED Spotlights, LED Grille Lamp, LED PAR Lamp

Size:80mm(L)×78mm(W)×25mm(H)

Weight:260g

Warranty:Five years



1. Operating Temperature: Tc 90C (max), Reference Ta −30 to +60°C;

2. Storage Temperature: −40 to +85°C;

3. Humidity (non-condensing): 5% to 95%RH;

4. Cooling: Convection;

5. Vibration Frequency: 5 ~ 55HZ/2g, 30 minutes;

6. Impact Resistance: 1g/S;

7. MTBF@40°C: 510,000 hours @ Full Load per MIL-217 Notice 2.;

8. LIFE@25°C: 110,000 hours @ Full Load per MIL-217 Notice 2.;

9. Safety: CISPR 22 CLASS B, CISPR 14-1 CLASS B,

EN61000-3-2 & EN61000-3-3 Class C,

GB19510.14-2009, GB19510.1-2009,

GB17743.1-2007, GB17625.1-2003

a. Maximum Input Current: 0.30A (@ 120V, full load);

b. Input Surge Current: <25A (25°C, 230V, cold start);

c. Constant Current Regulation: ±10%, Over Input Line Variation;

d. Load Regulation Accuracy: ±3%;

e. Output Current Ripple: <30%*Io

f. Leakage Current: 400uA typical; Hold up time: half cycle;

g. Protection: Output over-voltage protection;

Output over-current protection;

Output short circuit, auto-recovery;

Lightning & transient protection built in.
