New Led Outdoor Spot Light Garden Spotlights DC24V IP66 WAJTS-D114
New Led Outdoor Spot Light Garden Spotlights DC24V IP66 Description Our spotlight is suitable for landscape and building lighting, the product adopts modern minimalist design and perfect design for appearance under the premise of meeting practical functions. The circular shade of the luminaire...
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Description
Our spotlight is suitable for landscape and building lighting, the product adopts modern minimalist design and perfect design for appearance under the premise of meeting practical functions.
The circular shade of the luminaire is an excellent glare control for visual comfort, allowing the light distribution direction of the luminaire to be changed and the glare shield to be adjusted according to the visual needs of the human eye. In the case of strong anti-glare (such as park applications), built-in anti-glare grille devices with rotating anti-glare hoods can be selected to achieve perfect anti-glare treatment.
Under the condition of ensuring the appearance consistency design, the ability of heat dissipation is fully considered, and the design of chimney type wind-driven heat dissipation effect is adopted for scientific heat dissipation.
Easy installation: It can be applied as wall light or flood light, and the horizontal irradiation direction of the luminaire can be easily adjusted after the luminaire base is installed, without removing the base and re-fighting the screws to install.
The surface of the luminaire adopts high-grade spraying treatment form to strengthen the adhesion and make the luminaire outdoor application as new for a long time.
Features:
1. Multi-purpose outdoor spot light with minimalist design, suitable for outdoor key area lighting and It is suitable for outdoor key area lighting and floodlighting of building small column, park bridge, railing, plant, etc;
2. Integrated built-in heat sink design, heat dissipation of the whole lamp, practical ambient temperature range -30~60°. Electrical safety class III;
3. The lamp body is made of aluminum alloy with precision die-casting, stainless steel screws and waterproof structure.
4. The lamp body has its own dial and locking design.
5. Hood type anti-glare structure design, high luminous efficiency PMMA optical lens.
6. Waterproof breathing valve installed in the lamp body;
7. High-strength ultra-white tempered glass with 92% light transmission rate.
8. Large angle adjustment, can be used as a spotlight or wall lamp.
9. Surface treatment: gray or silver outdoor advanced spraying.
10. Light source: High power LED beads ( CREE as standard, optional)
11. Color rendering index: Ra ≥ 80
12. Protection level: IP66
13. Operating voltage: DC24V
14. Control mode: switch control
15. Installation: 0 ° to ~ 130 ° adjustable angle, installation chassis, can be ground or wall-mounted.
Product parameters：
| Model | WAJTS-D114 |
| Materials | Aluminium+Tempered Glass+PMMA |
| Power | 14W/18W |
| Lumen | 400lm |
| CRI | 1120lm/1440lm |
| Voltage | ＞80 |
| Color Temperature | 2200K/2700K/3000K/4000K |
| Finish | Black/White/Gray |
| Size | D114*H241mm |
| IP Rate | IP66 |
| Warranty | 2 Years |
Beam angle & Light distribution curve:
Multiple beam angles available, including 4°,8°,15°,30°.45°
Product Details:
Largeareaheatsink
Wind-drivenheatdissipationdesignofchimneyeffect
a: Anti-glare cover, high shading angle to ensure glare control
b: Anti-glare grille, which uses the depth of the grille to block the glare of the light source
c: Deep cavity structure design, the light source sinks, and concentrated light is projected onto the illuminated object.
360° rotatable hood design
After the lamp is installed, the shading direction of the hood can be adjusted according to the projection effect and human visual comfort to achieve a better anti-glare projection effect.
Precisely set angle adjustment
The dial with graduations facilitates precise alignment of the lamps. It ensures quick and easy setup, especially for lamps arranged in a row, which can be adjusted to the exact same tilt angle. The 55° adjustable tilt of the luminaire can be precisely adjusted to achieve the best beam alignment, and the light will be irradiated precisely where you need it.
