30W 0-10V Dimming Driver IP65 LPS30W-RD

Features:

a. Safety: EN61347, J61347 ( H20 ), UL8750, CSA C22.2

b. EMC: EN55015, J55015 ( H20 ), FCC 47CFR Part 15 Class B

c. Comply with PSE, CE & CCC

d. RoHs compliant;

e. Plastic Shell, Silicone Potting, Up to 120°C;

f. Compact, Lightweight Design;

g. Water Resistant and Dust Proof Design: IP65, NEMA4,

for Dry, Damp, Wet Locations;

h. Standard electrical box for installation;

i. Active Power Factor Correction technology to reduce

power consumption;

j. Safety Isolation between Primary and Secondary.



Product parameters：



0-10V Dimming	Input Voltage Vac	Power Factor		Output Voltage Vdc	Dimming Current mA	Current Accuracy %	Typical Efficiency %	Location
LPS30W-RD Series		@120V	@230V
LPS30W-85-C0350-RD	90~305	0.99	0.95	28-85	35-350	±5	89	Indoor
LPS30W-75-C0400-RD	90~305	0.99	0.95	25-75	40-400	±5	88	Indoor
LPS30W-66-C0450-RD	90~305	0.99	0.95	22-66	45-450	±5	87	Indoor
LPS30W-54-C0560-RD	90~305	0.99	0.95	18-54	54-540	±5	87	Indoor
LPS30W-42-C0700-RD	90~305	0.99	0.95	14-42	70-700	±5	87	Indoor
LPS30W-36-C0830-RD	90~305	0.99	0.95	12-36	83-830	±5	86	Indoor
LPS30W-24-C1250-RD	90~305	0.99	0.95	8-24	125-1250	±5	85	Indoor
LPS30W-18-C1660-RD	90~305	0.99	0.95	6-16	166-1660	±5	84	Indoor
LPS30W-12-C2530-RD	90~305	0.99	0.95	4-12	255-2530	±5	83	Indoor







Product type:0-10V Dimmable Driver

Application:LED Lamps, LED Spotlights, LED Grille, LED PAR Lamp

Size:132mm(L)×42mm(W)×25mm(H)

Weight:280g

Warranty:Five years



1. Operating Temperature: −30 to +60°C;

2. Storage Temperature: −40 to +85°C;

3. Humidity (non-condensing): 5% to 95%RH;

4. Cooling: Convection;

5. Vibration Frequency: 5 ~ 55HZ/2g, 30 minutes;

6. Impact Resistance: 1g/S;

7. MTBF@40°C: 510,000 hours @ Full Load per MIL-217 Notice 2.;

8. LIFE@25°C: 110,000 hours @ Full Load per MIL-217 Notice 2.;

9. Safety: CISPR 22 CLASS B, CISPR 14-1 CLASS B,

EN61000-3-2 & EN61000-3-3 Class C,

GB19510.14-2009, GB19510.1-2009,

GB17743.1-2007, GB17625.1-2003

a. Maximum Input Current: 0.30A (@ 120V, full load);

b. Input Surge Current: <25A (25°C, 230V, cold start);

c. Constant Current Regulation @ Dimming: ±5%;

d. Load Regulation Accuracy @ Dimming: ±3%;

e. 0-10V Input Signal: 0-10V, <2mA;

g. Output Current Ripple: <30%*Io

h. Leakage Current: 400uA typical; Hold up time: half cycle;

i. Protection: Output over-voltage protection;

Output over-current protection;

Output short circuit, auto-recovery;

Lightning & transient protection built in.
