120W Constant Current Driver IP66 LY120W
1. Drive Mode: Constant Current
2. Technology: PFC + LLC
3. Output Power: 120W Max.
4. Input Voltage: 90 to 305VAC，47-63HZ
5. Number of Outputs: One
6. Output Voltages: 4 ~ 343Vdc
7. Output Currents: 350mA - 10000mA
8. Safety: EN61347, J61347 ( H20 ), UL8750, CSA C22.2
9. EMC: EN55015, J55015 ( H20 ), FCC 47CFR Part 15 Class B
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Features:
a. Comply with PSE, CE & CCC
b. RoHs compliant;
c. Metal Shell, Silicone Potting, Up to 120°C;
d. Compact, Lightweight Design;
e. Water Resistant and Dust Proof Design: IP66, NEMA4, for Dry, Damp, Wet Locations;
f. Small electrical box for installation;
g. Active Power Factor Correction technology to reduce power consumption;
h. Safety Isolation between Primary and Secondary.
i. Surge Immunity ( Lightning Protection ): Comply with EN61000-4-5, AC line to line 2KV.
Product parameters：
| Compact and Efficient |
Input Voltage Vac |
Power Factor |
Output Voltage Vdc |
Constant Current mA |
Current Accuracy % |
Typical Efficiency % |
Location |
||||
|
LY120W Series |
@120V |
@230V |
|||||||||
| LY120W-343-C0350 | 90~305 | 0.99 | 0.95 | 114-343 | 350 | ±5 | 94 | Outdoor | |||
| LY120W-266-C0450 | 90~305 | 0.99 | 0.95 | 89-266 | 450 | ±5 | 94 | Outdoor | |||
| LY120W-171-C0700 | 90~305 | 0.99 | 0.95 | 57-171 | 700 | ±5 | 94 | Outdoor | |||
| LY120W-114-C1050 | 90~305 | 0.99 | 0.95 | 38-114 | 1050 | ±5 | 93 | Outdoor | |||
| LY120W-86-C1400 | 90~305 | 0.99 | 0.95 | 28-86 | 1400 | ±5 | 93 | Outdoor | |||
| LY120W-68-C1750 | 90~305 | 0.99 | 0.95 | 23-68 | 1750 | ±5 | 93 | Outdoor | |||
| LY120W-57-C2100 | 90~305 | 0.99 | 0.95 | 19-57 | 2100 | ±5 | 92 | Outdoor | |||
| LY120W-49-C2450 | 90~305 | 0.99 | 0.95 | 16-49 | 2450 | ±5 | 92 | Outdoor | |||
| LY120W-43-C2800 | 90~305 | 0.99 | 0.95 | 14-43 | 2800 | ±5 | 92 | Outdoor | |||
| LY120W-38-C3150 | 90~305 | 0.99 | 0.95 | 12-38 | 3150 | ±5 | 92 | Outdoor | |||
| LY120W-34-C3500 | 90~305 | 0.99 | 0.95 | 11-34 | 3570 | ±5 | 91 | Outdoor | |||
| LY120W-28-C4200 | 90~305 | 0.99 | 0.95 | 9-28 | 4200 | ±5 | 90 | Outdoor | |||
| LY120W-24-C5000 | 90~305 | 0.99 | 0.95 | 8-24 | 5000 | ±5 | 89 | Outdoor | |||
| LY120W-18-C6660 | 90~305 | 0.99 | 0.95 | 6-18 | 6660 | ±5 | 88 | Outdoor | |||
| LY120W-15-C8000 | 90~305 | 0.99 | 0.95 | 5-15 | 8000 | ±5 | 87 | Outdoor | |||
| LY120W-12-C10000 | 90~305 | 0.99 | 0.95 | 4-12 | 10000 | ±5 | 86 | Outdoor | |||
Product type:Compact and efficient, constant-current-driven
Application:LED Street Lights, LED Tunnel Lights, LED Grille
Size:170mm(L)×59mm(W)×37mm(H)
Weight:850g
Warranty:Five years
1. Operating Temperature: −30 to +60°C;
2. Storage Temperature: −40 to +85°C;
3. Humidity (non-condensing): 5% to 95%RH;
4. Cooling: Convection;
5. Vibration Frequency: 5 ~ 55HZ/2g, 30 minutes;
6. Impact Resistance: 1g/S;
7. MTBF@40°C: 500,000 hours @ Full Load per MIL-217 Notice 2.;
8. LIFE@25°C: 100,000 hours @ Full Load per MIL-217 Notice 2.;
9. Safety: CISPR 22 CLASS B, CISPR 14-1 CLASS B,
EN61000-3-2 & EN61000-3-3 Class C,
GB19510.14-2009, GB19510.1-2009,
GB17743.1-2007, GB17625.1-2003
a. Maximum Input Current: 1.50A (@ 120V, full load);
b. Input Surge Current: <40A (25°C, 230V, cold start);
c. Constant Current Regulation: ±3%, Over Input Line Variation;
d. Load Regulation Accuracy: ±3%;
e. Output Current Ripple: <1%*Io
f. Leakage Current: 400uA typical; Hold up time: half cycle;
g. Protection: Output over-voltage protection;
Output over-current protection;
Output short circuit, auto-recovery;
Lightning & transient protection built in.
