100W LED Solar Street Light Sensor Street Lamp IP65

Description:

It is an integrated solar street light that combines an ultra-bright Philips LED source, an intelligently programmed MPPT controller, and a lifePO4 battery pack. All of these components are incorporated inside the light fixture. The solar light head is connected to the solar panel using universal MC4 connections.

The large capacity LifePO4 battery pack is used, and it can work continuously with high power because the solar panel is separated from the light head, allowing the customer to select a suitable solar panel power based on their local solar radiation to ensure enough power is generated daily to meet the power consumption of the light. For example, for the same 50W light, the solar panel used in Saudi Arabia will only be 80W, when it should be 120W to 150W in Europe. The lighting program can be readily tweaked using the remote to save more energy, extending the battery's lifetime significantly with less depth of drain. It is CB and IECEE authorized.

Features:

1. MPPT CONTROLLER.
All series of street lights use an SRNE MPPT solar controller as the "CPU" of the system. Increasing charging efficiency by 30% above PWM.

2. LIFEPO4 BATTERY PACK
The LifePO4 battery pack has an extremely long lifetime and a large capacity, and it is built inside the light fixture. Without maintenance, the entire light can last for more than ten years. connection.

3. FSMD 3030 LED ENGINE
The PHILIPS SMD3030 LED engine is fitted and produces high lumens of up to 140lm per watt. The project budget could be reduced with a smaller layout.

4. Set by Romote.
The lighting program can be simply modified to meet the needs of the client, resulting in increased energy savings and a longer battery life.

5. SOLAR CABLE +MC4
2.5mm cable decreases power consumption wasted on components, while the MC4 connector allows for simple and long-lasting connections. Can connect to any solar panel using MC4.

6. MOTION SENSORS
More energy could be saved with the use of a motion sensor; this function could be turned on/off easily via remote control.

Product parameters：

Internal Structure

Size
