TL-TGD-I7203 Round Flood Light 216 W IP66 Aluminum
video
TL-TGD-I7203 Round Flood Light 216 W IP66 Aluminum

TL-TGD-I7203 Round Flood Light 216 W IP66 Aluminum

The TL-TGD-I7203 is a round flood light built as the largest 325 mm round body in the I series, measuring Diameter 325 × H375 mm. It runs on AC 100-250 V / DC 24 V with ON-OFF / DMX512 control and CREE LEDs, and seals to IP66 for year-round outdoor service. 4 versions share the housing: the I7203 at 216 W with CREE LEDs, and the I72F4 at 288 W in RGBW four-in-one color, the I1212 at 150 W in COB, the I1216 at 200 W in COB. Beam options run 6° to 60° at 2700K to 6000K, suiting big trees, silos and tall structures. Sourced from China, specifications and pricing on request.

Send Inquiry
  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

Description:

The TL-TGD-I7203 lights big trees, silos and tall structures from the largest 325 mm round body in the I series, the 216 W member of the TL-TGD round flood light family. 4 versions share the housing: the I7203 at 216 W with CREE LEDs, and the I72F4 at 288 W in RGBW four-in-one color, the I1212 at 150 W in COB, the I1216 at 200 W in COB. Beam options run 6° to 60° at 2700K to 6000K, and the housing seals to IP66. Control runs ON-OFF / DMX512 at AC 100-250 V / DC 24 V.



Features:

1. The largest 325 mm round body in the I series, 216 W, for big trees, silos and tall structures

2. Beam options from 6° to 60° across one housing, so the same fitting covers narrow accenting and wide washes

3. CREE LEDs with a constant current driver

4. High conductivity aluminum radiator with ventilation and convection design, SUS304 stainless steel screw bracket with a dial and gear locking

5. Monochrome and RGBW four-in-one output on the same housing, both running ON-OFF / DMX512 control



Product parameters:



Model TL-TGD-I7203 TL-TGD-I72F4 TL-TGD-I1212 TL-TGD-I1216
Materials Die-Cast Aluminum Die-Cast Aluminum Die-Cast Aluminum Die-Cast Aluminum
Power 216 W 288 W 150 W 200 W
LED Source CREE RGBW 4-in-1 COB COB
Light Output Monochrome RGBW full color Monochrome Monochrome
LED QTY 72 PCS 72 PCS 12 PCS 12 PCS
Control ON-OFF / DMX512 DMX512 ON-OFF ON-OFF
Beam Angle 6° / 8° / 10° / 15° / 30° / 45° / 60° 6° / 8° / 10° / 15° / 30° / 45° / 60° 6° / 8° / 10° / 15° / 30° / 45° / 60° 6° / 8° / 10° / 15° / 30° / 45° / 60°
CRI >80 Ra Not applicable >80 Ra >80 Ra
Voltage AC 100-250 V / DC 24 V AC 100-250 V / DC 24 V AC 100-250 V AC 100-250 V
Color Temperature 2700K / 3000K / 4000K / 6000K Not applicable 2700K / 3000K / 4000K / 6000K 2700K / 3000K / 4000K / 6000K
Finish Black / White / Platinum Grey / Shiny Grey Black / White / Platinum Grey / Shiny Grey Black / White / Platinum Grey / Shiny Grey Black / White / Platinum Grey / Shiny Grey
Size Diameter 325 × H375 mm Diameter 325 × H375 mm Diameter 325 × H375 mm Diameter 325 × H375 mm
IP Rating IP66 IP66 IP66 IP66
Warranty 2 Years 2 Years 2 Years 2 Years
MOQ 100 100 100 100



Installation drawing:

tl-tgd-i7203-floodlight-ip66-216w-aluminum-installation



Photometric distribution curves:

tl-tgd-i7203-floodlight-ip66-216w-aluminum-photometric-curves
