TL-TGD-I1803 Round Flood Light 54 W IP66 Aluminum
video
TL-TGD-I1803 Round Flood Light 54 W IP66 Aluminum

TL-TGD-I1803 Round Flood Light 54 W IP66 Aluminum

The TL-TGD-I1803 is a round flood light built as a 190 mm round body, measuring Diameter 190 × H260 mm. It runs on AC 100-250 V / DC 24 V with ON-OFF / DMX512 control and CREE LEDs, and seals to IP66 for year-round outdoor service. 3 versions share the housing: the I1803 at 54 W with CREE LEDs, and the I18F4 at 72 W in RGBW four-in-one color, the I0412 at 50 W in COB. Beam options run 6° to 60° at 2700K to 6000K, suiting medium trees and facade columns. Sourced from China, specifications and pricing on request.

Send Inquiry
  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

Description:

The TL-TGD-I1803 lights medium trees and facade columns from a 190 mm round body, the 54 W member of the TL-TGD round flood light family. 3 versions share the housing: the I1803 at 54 W with CREE LEDs, and the I18F4 at 72 W in RGBW four-in-one color, the I0412 at 50 W in COB. Beam options run 6° to 60° at 2700K to 6000K, and the housing seals to IP66. Control runs ON-OFF / DMX512 at AC 100-250 V / DC 24 V.



Features:

1. A 190 mm round body, 54 W, for medium trees and facade columns

2. Beam options from 6° to 60° across one housing, so the same fitting covers narrow accenting and wide washes

3. CREE LEDs with a constant current driver

4. High conductivity aluminum radiator with ventilation and convection design, SUS304 stainless steel screw bracket with a dial and gear locking

5. Monochrome and RGBW four-in-one output on the same housing, both running ON-OFF / DMX512 control



Product parameters:



Model TL-TGD-I1803 TL-TGD-I18F4 TL-TGD-I0412
Materials Die-Cast Aluminum Die-Cast Aluminum Die-Cast Aluminum
Power 54 W 72 W 50 W
LED Source CREE RGBW 4-in-1 COB
Light Output Monochrome RGBW full color Monochrome
LED QTY 18 PCS 18 PCS 4 PCS
Control ON-OFF / DMX512 DMX512 ON-OFF
Beam Angle 6° / 8° / 10° / 15° / 30° / 45° / 60° 6° / 8° / 10° / 15° / 30° / 45° / 60° 6° / 8° / 10° / 15° / 30° / 45° / 60°
CRI >80 Ra Not applicable >80 Ra
Voltage AC 100-250 V / DC 24 V AC 100-250 V / DC 24 V AC 100-250 V / DC 24 V
Color Temperature 2700K / 3000K / 4000K / 6000K Not applicable 2700K / 3000K / 4000K / 6000K
Finish Black / White / Platinum Grey / Shiny Grey Black / White / Platinum Grey / Shiny Grey Black / White / Platinum Grey / Shiny Grey
Size Diameter 190 × H260 mm Diameter 190 × H260 mm Diameter 190 × H260 mm
IP Rating IP66 IP66 IP66
Warranty 2 Years 2 Years 2 Years
MOQ 100 100 100



Installation drawing:

tl-tgd-i1803-floodlight-ip66-54w-aluminum-installation



Photometric distribution curves:

tl-tgd-i1803-floodlight-ip66-54w-aluminum-photometric-curves
