BE-SPL0306 Spot Light 3 W / 5 W IP67 Aluminium
The BE-SPL0306 and BE-SPL0506 are die casting aluminium LED spot lights for accent and shrub lighting in gardens, pathways, courtyards and building facades. Two power tiers share one die-cast housing family: 3 W (250 lm) and 5 W (550 lm), with beam-angle options of 20° / 40° / 60° on the 3 W tier and 24° / 40° / 60° on the 5 W tier at 2700 K / 3000 K / 4000 K, sealed to IP67 in a powder coated black finish. Version A keeps a flush barrel front at 98 mm long; Version B adds an anti-glare shroud and extends to 138 mm. Both run on 12 / 24 V DC with a built-in DC driver and a 2 m power cable. Mounting is by a U-shaped bracket on solid ground, with an optional ground spike for soft ground. Sourced from China with full specifications and pricing available on request.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Description:
The BE-SPL0306 and BE-SPL0506 (versions A / B) are die casting aluminium LED spot lights for accent and shrub lighting in gardens, pathways, courtyards and building facades. Two power tiers share one die-cast housing family: 3 W (250 lm) and 5 W (550 lm), with beam-angle options of 20° / 40° / 60° on the 3 W tier and 24° / 40° / 60° on the 5 W tier at 2700 K / 3000 K / 4000 K, sealed to IP67 in a powder coated black finish. It runs on 12 / 24 V DC with a built-in DC driver and a 2 m power cable; as with other built-in-driver models in this range, size the supply with a start-up margin above the lamp rating so the LED starts reliably. Version A keeps a flush barrel front at 98 mm long, while Version B adds an anti-glare shroud and extends to 138 mm. Mounting is by a U-shaped bracket on solid ground, with an optional ground spike for soft ground. Sourced from China as a specification-compliant commercial-grade spot light.
Features:
1. Two power tiers in one die-cast housing family: 3 W / 250 lm and 5 W / 550 lm, so one design covers both marker accents and brighter shrub uplighting
2. Die-cast aluminium body in a powder coated black finish - a sprayed paint process, distinct from the anodized finishes used elsewhere in the range
3. An anti-glare shroud on Version B shields the lens from direct view along pathways and seated sightlines
4. 12 / 24 V DC input with built-in DC driver; size the supply with a start-up margin above the 5 W rating for reliable LED start-up
Product parameters:
| Model | BE-SPL0306A | BE-SPL0306B | BE-SPL0506A | BE-SPL0506B |
| Face Version | Flush barrel front | Anti-glare shroud | Flush barrel front | Anti-glare shroud |
| Materials | Die-Cast Aluminium | Die-Cast Aluminium | Die-Cast Aluminium | Die-Cast Aluminium |
| Power | 3 W | 3 W | 5 W | 5 W |
| Lumen | 250 lm | 250 lm | 550 lm | 550 lm |
| Beam Angle | 20° / 40° / 60° | 20° / 40° / 60° | 24° / 40° / 60° | 24° / 40° / 60° |
| Voltage | 12 / 24 V DC | 12 / 24 V DC | 12 / 24 V DC | 12 / 24 V DC |
| Color Temperature | 2700 K / 3000 K / 4000 K | 2700 K / 3000 K / 4000 K | 2700 K / 3000 K / 4000 K | 2700 K / 3000 K / 4000 K |
| Finish | Powder Coated Black | Powder Coated Black | Powder Coated Black | Powder Coated Black |
| Size | Ø45 × 98 mm | Ø50 × 138 mm | Ø45 × 98 mm | Ø50 × 138 mm |
| IP Rating | IP67 | IP67 | IP67 | IP67 |
| Warranty | 3 Years | 3 Years | 3 Years | 3 Years |
| MOQ | 100 | 100 | 100 | 100 |
Face Versions:
Version A (BE-SPL0306A / BE-SPL0506A): flush barrel front with the lens recessed in the housing, 98 mm long
Version B (BE-SPL0306B / BE-SPL0506B): lens fitted with an anti-glare shroud for a darker, cut-off front, 138 mm long
Product Size:
Version A (flush barrel front): Ø45 × 98 mm.
Version B (anti-glare shroud): Ø50 × 138 mm.
Beam Angle & Illuminance Diagram:
Optional Accessories:
Optional anti-glare glass lenses (WUAG04L linear / WUAG04S soften) and the WUAH01 honeycomb louver fit the front bezel. IP68 junction boxes for single-lamp (JB2001) or continuous-run (JB3001) installation and a ground spike (SPAS01) are also available, all ordered separately.
