TL-TGD-K1203 Round Flood Light 36 W IP66 Die-Cast Aluminum
video
TL-TGD-K1203 Round Flood Light 36 W IP66 Die-Cast Aluminum

TL-TGD-K1203 Round Flood Light 36 W IP66 Die-Cast Aluminum

The TL-TGD-K1203 is a round flood light built as a 180 mm waist-drum body, measuring Diameter 180 × H190 mm. It runs on AC 100-250 V / DC 24 V with ON-OFF control and CREE LEDs, and seals to IP66 for year-round outdoor service. 3 versions share the housing: the K1203 at 36 W with CREE LEDs, and the K4801 at 36 W in OSRAM multi-chip LEDs, the K18F4 at 72 W in RGBW four-in-one color. Beam options run 6° to 60° at 2700K to 6000K, suiting tree groups and mid-height walls. Sourced from China, specifications and pricing on request.

Send Inquiry
  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

Description:

The TL-TGD-K1203 lights tree groups and mid-height walls from a 180 mm waist-drum body, the 36 W member of the TL-TGD round flood light family. 3 versions share the housing: the K1203 at 36 W with CREE LEDs, and the K4801 at 36 W in OSRAM multi-chip LEDs, the K18F4 at 72 W in RGBW four-in-one color. Beam options run 6° to 60° at 2700K to 6000K, and the housing seals to IP66. Control runs ON-OFF at AC 100-250 V / DC 24 V.



Features:

1. A 180 mm waist-drum body, 36 W, for tree groups and mid-height walls

2. Beam options from 6° to 60° across one housing, so the same fitting covers narrow accenting and wide washes

3. CREE LEDs with a constant current driver

4. Die-cast aluminum body with SUS304 stainless steel screws and an electrostatic sprayed surface, bracket with a graduated dial and gear lock

5. Monochrome and RGBW four-in-one output on the same housing, both running ON-OFF control



Product parameters:



Model TL-TGD-K1203 TL-TGD-K4801 TL-TGD-K18F4
Materials Die-Cast Aluminum Die-Cast Aluminum Die-Cast Aluminum
Power 36 W 36 W 72 W
LED Source CREE OSRAM RGBW 4-in-1
Light Output Monochrome Monochrome RGBW full color
LED QTY 12 PCS 48 PCS 18 PCS
Control ON-OFF ON-OFF / DMX512 DMX512
Beam Angle 6° / 8° / 10° / 15° / 30° / 45° / 60° 6° / 8° / 10° / 15° / 30° / 45° / 60° 6° / 8° / 10° / 15° / 30° / 45° / 60°
CRI >80 Ra >80 Ra Not applicable
Voltage AC 100-250 V / DC 24 V AC 100-250 V / DC 24 V AC 100-250 V / DC 24 V
Color Temperature 2700K / 3000K / 4000K / 6000K 2700K / 3000K / 4000K / 6000K Not applicable
Finish Black / White / Platinum Grey / Shiny Grey Black / White / Platinum Grey / Shiny Grey Black / White / Platinum Grey / Shiny Grey
Size Diameter 180 × H190 mm Diameter 180 × H190 mm Diameter 180 × H190 mm
IP Rating IP66 IP66 IP66
Warranty 2 Years 2 Years 2 Years
MOQ 100 100 100



Installation drawing:

tl-tgd-k1203-floodlight-ip66-36w-aluminum-installation



Photometric distribution curves:

tl-tgd-k1203-floodlight-ip66-36w-aluminum-photometric-curves
