CREE LED Wall Washer TL-XQD-K1803 54 W 3-60 Beam

CREE Linear Wall Washer, 54 W, 3°–60° Beam & DMX512

The K1803 is a single 54 W wall washer, 1000 mm long and IP66, in a 64x108 mm housing, and the only wall washer in the range built on CREE LEDs. Its beam is selectable from 3 up to 60 degrees, with DMX512 control with automatic addressing. Pick the beam, and the order sheet carries the model number.

The K1803 is the only wall washer in the range built on CREE LEDs. Its beam is selectable from 3° up to 60°: the 3° optic throws a narrow shaft that travels far without spreading, for tower crowns, landmark outlines and upward light shafts, while the wider angles give an even wash across the wall. It comes in a single 54W single-color version, on AC220V or DC24V, in the same 64×108 mm body as the K4801.

The K1803 is a single model: 54 W single color, CREE LEDs, beam selectable from 3° to 60°.

Beam Options (choose per order)

Beam angles are selectable from 3° up to 60°. The 3° optic throws a narrow shaft that travels far without spreading, for tower crowns and landmark outlines; the wider angles give an even wash across the wall.

Color & Control

Single color models run ON-OFF or through DMX512 dimming, and accept direct AC input so outdoor runs can skip a separate driver. RGBW 4-in-1 models put red, green, blue and white in one LED for full color mixing, driven per fixture over DMX512 with automatic addressing.

Housing & Build

6063 aluminum body, SUS304 stainless steel screws and a double slider mounting bracket, finished in outdoor electrostatic coating. The seal is structural with no glue process, rated IP66, with an inner cavity heat dissipation and an optional anti-glare shield.
