TL-TGD-KA0603 Anti-Glare Round Flood Light 18 W IP66 Die-Cast Aluminum

Description:

The TL-TGD-KA0603 lights areas where glare control matters near eye level from a 231 mm round body with an anti-glare cover, the 18 W member of the TL-TGD anti-glare round flood light family. 3 versions share the housing: the KA0603 at 18 W with CREE LEDs, and the KA2401 at 24 W in OSRAM multi-chip LEDs, the KA12F4 at 48 W in RGBW four-in-one color. Beam options run 6° to 60° at 2700K to 6000K, and the housing seals to IP66. Control runs ON-OFF at AC 100-250 V / DC 24 V.

Features:

1. A 231 mm round body with an anti-glare cover, 18 W, for areas where glare control matters near eye level

2. Beam options from 6° to 60° across one housing, so the same fitting covers narrow accenting and wide washes

3. CREE LEDs with a constant current driver

4. Die-cast aluminum body with SUS304 stainless steel screws and an electrostatic sprayed surface, bracket with a graduated dial and gear lock

5. Monochrome and RGBW four-in-one output on the same housing, both running ON-OFF control

Product parameters:

Installation drawing:

Photometric distribution curves:
